Hikvision DS-2XS6A87G1-L/C32S80 Acusense 8MP 4G kit

Please login or register to see price

More Information
Type of Product Camera
Technology Solar
Megapixel 8MP
Colour White
Camera Style Bullet
Lens 2.8mm Fixed Lens
Max Resolution 3840 x 2160
IR Range N/A
Internal / External External
IP Rating IP67
WDR Yes
Vandal Resistant N/A
Power 12VDC
Manufacturer Hikvision
Box Quantity 1
Please login or register now to add to cart Compare This Product

Description

Hikvision Hikvision DS-2XS6A87G1-L/C32S80 Acusense 8MP 4G kit Battery sold separately.

Hikvision DS-2XS6A87G1-L/C32S80 EXIR Fixed Bullet Solar Power 4G Network Camera Kit



Highlighted features of DS-2XS6A87G1-L/C32S80:
    • 8MP high resolution
    • 2.8mm fixed lens
    • Full time colour
    • Triple stream
    • Up to 30m White light
    • H.265+ compression
    • 6 analytics
    • IP67 weatherproof
    • 120dB wide dynamic range
    • Supports on board storage (up to 256GB)
    • 80W photovoltaic panel, 30 Ah chargeable lithium battery (The battery should be ordered separately.)
    • Support battery management, battery display, battery high-low temperature protection, charge-discharge protection, low-battery sleep protection and remote
      wakeup
    • LTE-TDD/LTE-FDD/WCDMA/GSM 4G wireless network transmission, support Micro SIM card
    • 12V DC

Check out the turret version of this camera here.

Do you need any help?
Why not give us a call on 0161 791 2351 or 0161 879 9191.

Additional information

Brand

Hikvision

Megapixel

2MP

Lens

2.8mm

Color

White

Camera Shape

Bullet

Casing material

Main body: Metal

Spec Sheet

Specification
Camera
Image Sensor 1/1.2″ Progressive Scan CMOS
Min. Illumination Color: 0.0005 Lux @ (F1.0, AGC ON), B/W: 0 Lux with white light
Max. Resolution 3840 × 2160
Shutter Speed 1 s to 1/100,000 s
Lens
Lens Type Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV: 101.6°, vertical FOV: 52.4°, diagonal FOV: 124°
4 mm, horizontal FOV: 88.2°, vertical FOV: 48.7°, diagonal FOV: 101.8°
Iris Type Fixed
Lens Mount M20
Aperture F1.0
DORI
DORI
2.8 mm: D: 44 m, O: 17.5 m, R: 9 m, I: 4.5 m
4 mm: D: 53 m, O: 21 m, R: 11 m, I: 5 m
Illuminator
Supplement Light Type White Light
Supplement Light Range Up to 30 m
Smart Supplement Light Yes
Video
Main Stream
50 Hz: 12.5 fps (3840 × 2160, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (3840 × 2160, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 12.5 fps (640 × 480, 640 × 360)
60 Hz: 15 fps (640 × 480, 640 × 360)
Video Compression
Main stream: H.265
Sub-stream: H.265/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.265 Type Main Profile
H.265+ Full power mode: main stream supports
Bit Rate Control CBR/VBR
Scalable Video Coding (SVC) H.265 encoding
Region of Interest (ROI) 4 fixed regions for main stream
Network
Simultaneous Live View Up to 6 channels
API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP,UPnP, SMTP,
SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
User/Host Up to 32 users. 3 user levels: administrator, operator and user
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication
(EAP-MD5), watermark, IP address filter, basic and digest authentication for
HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface,
RTP/RTSP over HTTPS, control timeout settings, TLS 1.2

CCTV Lens Guide

Battery sold separately

It can be used in the areas that are not suitable for laying wired network and electric supply lines, or used for the scenes that feature tough environment and have high demanding for device stability. It can be used for monitoring the farms, electric power cables, water and river system, oil pipelines and key forest areas. It also can be used in the temporary monitoring scenes, such as the large-scale competitions, the sudden public activity, the temporary traffic control and the city construction. Hikvision ColorVu technology provides 24/7 vivid colorful images with F1.0 advanced lenses and high performance sensors. F1.0 super-aperture collects more light to produce brighter images. Advanced sensor technology can vastly improve the utilization of available light. Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.
